Valves
Browse by Model
Model 2570Posi-Temp® Valve
Model 3372 Two or ThreeFunction Transfer Valve
Model 3570Moentrol® Spa Valve
Model S3102 U By Moen™Shower Digital Valve
Model S3104 U By Moen™Shower Digital Valve
Model S3371 ExactTemp®¾” Thermostatic Valve
Model S3600 ExactTemp®Thermostatic Volume
Control & Transfer Valve
U by Moen™ Shower
Digital thermostatic with computer and mobile app-controlled temperature and flow.
ExactTemp® ¾” Thermostatic Valve
Mechanical thermostatic control.
Moentrol® Valve
Pressure-balancing volume control valve.
Two- or Three-Function Moentrol Valve
Volume and temperature control across multiple outlets. Handle pulls out to adjust flow and rotates from hot to cold.
Posi-Temp® Valve
Pressure-balancing cycling valve.
Two- or Three-Function Transfer Valve
Directs water flow to spray outlets.
Browse by Model
Model: 2570
Posi-Temp® Valve
Also called a "cycling valve," the Posi-Temp Valve is a design that uses the 1222 high-flow pressure-balancing cartridge.
HOW IT IS USED:
Shower and tub applications. Expandable to multi-outlet with addition of a transfer valve.
INSTALLATION:
Flexible installation options including copper, CPVC, crimp ring PEX, cold expansion PEX, and IPS. Valve options include quarter-turn stops to prevent the necessity to shut off water at the main line.
QUICK FIX:
Be sure to turn off the water before replacing the cartridge.
BENEFITS:
- Flow reversibility
- Set maximum temperature upon installation
- Vertical spa compatibility
- Back-to-back installation capability
How To Install Posi-Temp Valve 2570
Model: 3372
Two- or Three-Function Transfer Valve
Transfer valves can be used in combination with Posi-Temp® and Moentrol® valves.
HOW IT IS USED:
Designed for two-outlet applications. Activates individual outlets for body sprays, handshowers or an extra showerhead. Two-function equals two independent functions. Three-function equals two independent and one shared function.
Model: 3570
Two- or Three-Function Moentrol® Valve
The Moentrol valve has a pressure-balancing mechanism and uses the 1225 cartridge. It can adapt to Moen's two- or three-function transfer valves as needed for the addition of handshowers or for vertical spas. The Moentrol valve is also available with an integrated two- or three-function transfer valve option. The Moentrol valves also feature both temperature and volume control.
HOW IT IS USED:
One-handle faucets and shower/tub applications. Separate hot and cold inlets and single outlet. Additional functionality with the two- or three-function Moentrol valve.
INSTALLATION:
Set temperature limit at install. Accommodates standard ½” connections. IPS and CC options available.
QUICK FIX:
Most servicing can be done without turning off the water due to built-in shut-offs (or stops) by simply replacing the cartridge.
BENEFITS:
- Set maximum water temperature and temperature memory
- Installation works with common household plumbing
- Meets shower shock safety codes
- Integrates with Moen M•PACT® Common Valve System
- ExactTemp® to allow faucet replacement without replacing any plumbing
How to Install Moentrol Valve 3570
Model: S3371
ExactTemp® ¾” Thermostatic Valve
The ExactTemp valve uses thermostatic technology for precise temperature control and high-volume capability to feed multiple showering devices.
HOW IT IS USED:
Used in showers ranging from single-head to vertical spa when combined with volume control valves including the ExactTemp Volume Control Transfer Valve. Hot and cold inlets feed water through valve unit.
INSTALLATION:
Accommodates ¾” IPS inlets and outlets that can accept ½” adapters.
BENEFITS:
- Set maximum water temperature and temperature memory
- Installation works with common household plumbing
- Meets shower shock safety codes
- Integrates with Moen M•PACT® Common Valve System
How to Install ExactTemp Valve S3371
Model: S3600
ExactTemp® Volume Control Transfer Valve
This transfer valve can be used in combination with the ExactTemp 3/4" Thermostatic Valve to add volume control to ExactTemp's precise temperature control. Additional volume-control valves can be added to support handshowers, body sprays and other functions.
HOW IT IS USED:
Designed for two-outlet applications. Activates individual outlets for body sprays, handshowers or an extra showerhead. Two-function equals two independent functions. Three-function equals two independent and one shared function.
Model: S3102
U By Moen Shower 2-Outlet Thermostatic Digital Shower Valve
U by Moen shower gives users the ability to control and customize their shower using both the digital controller and optional smartphone app.
HOW IT IS USED:
2- or 4- outlet models are available for standard shower and vertical spa configurations. Standard hot and cold water inlets and outlets are used.
INSTALLATION:
Installation is easy due to the valve's compact size and flexible placement within 6 feet of a GFCI outlet. A 30-foot waterproof data cable connects the valve and controller.
BENEFITS:
- Precise temperature control
- U by Moen cloud-based Wi-Fi infrastructure
- Flexible installation and configuration options
How to Install U by Moen
Model: S3104
U By Moen Shower 4-Outlet Thermostatic Digital Shower Valve
U by Moen shower gives users the ability to control and customize their shower using both the digital controller and optional smartphone app.
HOW IT IS USED:
2- or 4- outlet models are available for standard shower and vertical spa configurations. Standard hot and cold water inlets and outlets are used.
INSTALLATION:
Installation is easy due to the valve's compact size and flexible placement within 6 feet of a GFCI outlet. A 30-foot waterproof data cable connects the valve and controller.
BENEFITS:
- Precise temperature control
- U by Moen cloud-based Wi-Fi infrastructure
- Flexible installation and configuration options
How to Install U by Moen
Pressure-Balancing
Protects users from "shower shock" due to a sudden change in either hot- or cold-water pressure elsewhere in the plumbing system (i.e., toilet flush). Pressure-balancing valves are designed to detect the pressure drop and automatically adjust the flow of water to maintain a consistent water temperature.
Thermostatic
These valves use a device to keep temperature consistent. They typically require a separate volume-control function, such as a transfer valve.
Cycling Valve
Turns on and off, cycling counter clockwise from cold (6 o'clock) to hot (9 o'clock). Does not provide volume control.
Volume Control
Allows the user to adjust water flow rates as other plumbing fixtures connected to the line are in use.
